9 Elementary Data Structures

Data Abstraction

Data abstraction is a process of hiding the implementation details of data structures and operations, while exposing only the essential features and functionalities to the user.

9.1 Array

Array

An array is a fixed collection of same-type data that are stored contiguously and that are accessible by an index.

A dynamic array is an array whose size can be changed during the execution of the program.

Example of The sieve of Eratosthenes

A simple program prints out all prime numbers less than N.

void sieve(int N) {
    int i;
    int *a = new int[N];
    for (i = 2; i < N; i++) a[i] = 1;
    for (i = 2; i < N; i++)
        if (a[i])
            for (int j = i; i*j < N; j++) a[i*j] = 0;
    for (i = 2; i < N; i++)
        if (a[i]) cout << " " << i;
    delete[] a;
}

Challenge: analysis the program

9.2 Linked Lists

Linked Lists

A linked list is a set of items where each item is part of a node that also contains a link to a node. It allows the items be arranged in a linear order.

Example of Josephus Election

Imagine that N people have decided to elect a leader by arranging themselves in a circle and eliminating every Mth person around the circle, closing ranks as each person drops out. The problem is to find out which person will be the last one remaining
If N=9 and M=5

Singly Linked Lists

Data Structure for List Node

We use pointers for links and structures for nodes

struct ListNode {
    DataType data;
    ListNode *next;
    ListNode(DataType data, ListNode *next=nullptr) {
        this->data = data;
        this->next = next;
    }
};
typedef ListNode *Link;

Create a List Node

Creating a new node

ListNode *p = new ListNode(...);

We so often need to use the phrase “the node referenced by link p” that we simply say “node p”
It is a null link that points to no node.
It refers to a dummy node that contains no data.

Delete a List Node

Deleting a node

ListNode *p;
...
delete p;

Writing a function to delete a node

void deleteNode(ListNode *p)
{
    ...
}

Deep Deletion

Deleting a node and its link
Writing a function to delete a node deeply

void deepDeleteNode(ListNode *p)
{
    ...
}

Organize a Linked List

Data Structure for Linked List

struct LinkedList {
    ListNode *first; // or ListNode *head;
    LinkedList() {
        this->first = nullptr;
    }
};

Insert at The Beginning

Traversing a Linked List

Assign List head to node pointer.
while node pointer is not null
    Display the value member of the node pointed to by node pointer.
    Assign node pointer to its own next member.

Another Data Structure for Linked List

struct LinkedList {
    ListNode *first;
    ListNode *last;
    LinkedList() {
        this->first = nullptr;
        this->last = nullptr;
    }
};

Insert at The End

Remove from The Beginning

Search

ListNode *search(ListNode *first, DataType k)  {
    ListNode *current = first;
    while(current) {
        if (current->data == k) then return current;
        current = current->next;
    }
    return nullptr;
}

Ordered Linked List

An ordered linked list is a data structure that maintains a collection of elements in a linear sequence. The elements in an ordered linked list are arranged in a specific order, such as ascending or descending, based on the values of the elements.

Insert

Create a new node.
Store data in the new node.
if there are no nodes in the list then
    Make the new node the first node.
else
    Find the first node whose value is greater than or equal to the new
        value, or the end of the list (whichever is first).
    Insert the new node before the found node, or at the end of the list
        if no such node was found.

Dummy Head Node

A dummy head node is a head node that does not store any actual data related to the problem.

Sort

Sorting an unordered linked list is arranging the elements of the list in a specific order, typically ascending or descending

9.3 Variations on Linked List

Circular Linked Lists

Circular linked list is a variation of linked list in which the last element points to the first element (or the first element points to the last element and).

Doubly Linked Lists

Doubly linked is a variation of linked list in that it has two pointers. One points to the next node as before, while the other points to the previous node.

Generalized Lists

How to Extend Linked List

We can extend a data structure of linked list by abstracting - Data field - Link field

Multi-Linked List

A multi-linked list is a variation of the traditional linked list data structure where each node can have multiple pointers, or references, to other nodes, creating a hierarchical structure.

Skip List

Multi-Linked List

Generalized Lists

A generalized list l is a finite sequence of n\geq0 elements, \{e_{0},e_{1},\ldots,e_{n-1}\}, where e_{i} is either an element or a generalized list.

struct GenListNode {
    bool tag;
    GenListNode* next;
    union {
        DataType data;
        GenListNode* down;
    };
};

Consider the generalized list L=((a,b,c),((d,e),f),g)

9.4 Stack

Stack

A stack is a data structure that stores and retrieves items in a last-in-first- out (LIFO) manner.

Stack API

method	description
`boolean isEmpty()`	is the stack empty?
`int size()`	number of items in the stack
`void push(Item item)`	add item to the stack
`Item top()`	most recently added item
`void pop()`	remove the most recently added item

Stack applications

Parsing in a compiler.
Java virtual machine.
Undo in a word processor.
Back button in a Web browser.
PostScript language for printers.
Implementing function calls in a compiler.
…

Function calls

How a compiler implements a function.
- Function call: push local environment and return address.
- Return: pop return address and local environment.

Remove recursion

Recursive function: Function that calls itself.
Can always use an explicit stack to remove recursion.
Challenge: reimplement quicksort without using recursion

Arithmetic expression

Arithmetic expression can be represented in

infix

⟨operand 1⟩ ⟨operator⟩ ⟨operand 2⟩
prefix (Polish Notation)

⟨operator⟩ ⟨operand 1⟩ ⟨operand 2⟩
postfix (Reverse-Polish Notation)

⟨operand 1⟩ ⟨operand 2⟩ ⟨operator⟩

infix	prefix	postfix
`A+B*C`	`+*BCA`	`BC*+A`
`(A-B)/C`	`/-ABC`	`AB-C/`
`(A+B)*(C-D)`	`*+AB-CD`	`AB+CD-*`

Conversion of an infix expression to postfix

Convert infixExp to postfixExp

stackOps.push('(')
infixExp.append(')')
while not infixExp.end()?
    tok ← infixExp.nextToken()
    if tok is operand then postfixExp.append(tok)
    if tok is "(" then stackOps.push(tok)
    if tok is operator then
        while precedence of stackOps.top() is higher than or equal tok?
            postfixExp.append(stackOps.pop())
            stackOps.push(tok)
    if tok is ")" then
        while stackOps.top() is not "("?
            postfixExp.append(stackOps.pop())
        stackOps.pop()

Example

Convert the infix expression (A+B)*(C-(D+A)) into a postfix expression

`tok`	`stackOps`	`postfixExp`

Arithmetic expression evaluation

A simple version of two-stack algorithm proposed by E. W. Dijkstra

Scan tokens from the expression (fully parenthesized)
if token is
    - Value: push onto the value stack.
    - Operator: push onto the operator stack.
    - Left parenthesis: ignore.
    - Right parenthesis:
        - pop operator and two values.
        - push the result of applying that operator to those values onto the
        operand stack.

Evaluate the expression ( 1 + ( ( 2 + 3 ) * ( 4 * 5 ) ) )

Implementation (simple)

Input in is a arithmetic expression that is fully parenthesized and contains delimiters (space characters)

double evaluate(istream& in) {
    stack<string> ops;
    stack<double> vals;
    string tok;
    while (!in.eof()) {
        in >> tok;
        if (tok == "(");
        else if (tok == "+" || tok == "*") ops.push(tok);
        else if (tok == ")") {
            string op = ops.top(); ops.pop();
            double val2 = vals.top(); vals.pop();
            double val1 = vals.top(); vals.pop();
            if (op == "+") vals.push(val1 + val2);
            else if (op == "*") vals.push(val1 * val2);
        }
        else vals.push(stod(tok));
    }
    return vals.top();
}

9.5 Queue

Queue

A queue is a data structure that stores and retrieves items in a first-in- first-out (FIFO) manner.

Queue API

method	description
`boolean isEmpty()`	is the queue empty?
`int size()`	number of items in the queue
`void enqueue(Item item)`	add item to the queue
`void dequeue()`	remove the least recently added item
`Item front()`	the least recently added item

Queue applications

Operating systems (queuing messages, IO requests, mouse movements, etc),
Web servers (queuing incoming requests, file operations, etc)
Ticket counter line where people who come first will get his ticket first
Bank line where people who come first will done his transaction first
…

9.6 Deque

Deque

The deque stands for Double Ended Queue. Deque is a linear data structure where the insertion and deletion operations are performed from both ends. We can say that deque is a generalized version of the queue.

Some restricted deques

If we insert at the end and remove at the end, we get a stack
if we insert at the end and remove at the beginning, we get a FIFO queue

Array-based deque

Deque API

method	description
`void push_front(Item item)`	Insert item at the front
`void push_back(Item item)`	Insert item at the back
`void pop_front()`	Remove at the front
`void pop_back()`	Remove at the back
…

9.7 Symbol Tables

Introduction

A symbol table is a data structure of key-value pair abstraction that supports two basic operations:

Insert a value (item) with specified key.
Given a key, search for the corresponding value.

For example, DNS lookup.
- Insert domain name with specified IP address.
- Given domain name, find corresponding IP address.

Symbol table applications

Application	Purpose Of Search	Key	Value
dictionary	find definition	word	definition
book index	find relevant pages	term	list of page numbers
file share	find song to download	name of song	computer ID
financial account	process transactions	account number	transaction details
web search	find relevant web pages	keyword	list of page names
compiler	find properties of variables	variable name	type and value
routing table	route Internet packets	destination	best route
DNS	find IP address	domain name	IP address
reverse DNS	find domain name	IP address	domain name
genomics	find markers	DNA string	known positions
file system	find file on disk	filename	location on disk

Abstract Data Type

Symbol-Table Abstract Data Type

template <class Key, class Value>
class SymbolTable {
private:
    // Implementation-dependent code
public:
    int count() = 0;
    Value search(Key) = 0;
    void insert(Key, Value) = 0;
    void remove(Key) = 0;
    Key select(int) = 0;
};

Conventions

Value type:
- Any generic type.
- Values are not null. (nullValue)
Key type:
- Keys are any generic type.
- Keys are Comparable.
- Keys are unique and not null. (nullKey)

Ordered Symbol-Table Abstract Data Type

For ordered symbol-table, we need the following additional methods

Methods	Meanings
`Key min()`	smallest key
`Key max()`	largest key
`Key floor(Key key)`	largest key less than or equal to key
`Key ceiling(Key key)`	smallest key greater than or equal to key
`Key select(int k)`	key of rank k
`int rank(Key key)`	number of keys less than key
`vector<Key> range(int l, int r)`	keys in sorted set of keys [l..r]
`vector<Key> keys(Key lo, Key hi)`	keys in [lo..hi], in sorted order

Examples of ordered symbol table API

Elementary Implementations

Array-based Symbol Table

template <class Key, class Value>
class ArraySymbolTable: public SymbolTable<Key, Value> {
private:
    Value *values;
    Key *keys;
    int N;
public:
    ArraySymbolTable() {
        ...
    }
    ...
};

Sequential Search

The search function can scan through the array of keys to look for an item with the specified key, returning nullValue when encountering an item with a larger key

Value seqsearch(int l, int r, Key key) {
    for(int i=l; i<=r; i++)
        if (keys[i] == key) return values[i];
    return nullValue;
}
Value search(Key key) {
    return seqsearch(0, N-1, key);
}

Challenge: Can we make any improvement?
Analysis

Sequential search in a symbol table with N ordered items uses about N/2 comparisons for search hits andh search misses (on the average)

Binary Search

Idea

Given that the array keys is sorted, the search checks the middle element of the active region.

If the middle element is the target element, the search terminates.

Otherwise, the search recursively continues to the left or right half of the region, depending on the value of the middle element.

Value binsearch(int l, int r, Key key) {
    int m;
    do {
        m = (l + r) / 2;
        if (keys[m] == key)
            return values[m];
        else if (keys[m] > key)
            r = m - 1;
        else
            l = m + 1;
    } while (l <= r);
    return nullValue;
}

Challenge: Reimplement the function using recursion.
Analysis

Binary search never uses more than \log_{2}(N+1) comparisons for a search (hit or miss)

Interpolation Search

We can replace the formula m\gets l+\frac{1}{2}(r-l) with m\gets l+\frac{key-keys[l]}{keys[r]-keys[l]}(r-l)

Selection

Problem. Finding the k-th smallest of a set of keys without required full sort.

template <class Item>
void select(Item a[], int l, int r, int k) {
    if (r <= l) return;
    int i = partition(a, l, r);
    if (i > k) select(a, l, i - 1, k);
    if (i < k) select(a, i + 1, r, k);
}

Challenge: reimplement the function without using recursion
Analysis

Quicksort-based selection is linear time on the average

Cost summary for basic symbol-table implementations

implementation	search (worst)	insert (worst)	remove (worst)	search hit (avg)	insert (avg)	remove (avg)	ordered iteration	key
unordered list	N	1	N	N/2	1	N/2	no	equal
ordered list	N	N	N	N/2	N/2	N/2	yes	compare
ordered array	\log_{2}N	N	N	\log_{2}N	N/2	N/2	yes	compare
goal?

9.8 Workshop

Quiz

What is a linked list?
What is a stack?
What is a queue?
A letter means push and an asterisk means pop in the sequence EAS*Y*QUE***ST***IO*N***

Give the sequence of values returned by the pop operations.
An uppercase letter means put at the beginning, a lowercase letter means put at the end, a plus sign means get from the beginning, and an asterisk means get from the end in the sequence EAs+Y+QUE**+st+*+IO*n++*

Give the sequence of values returned by the get operations when this sequence of operations is performed on an initially empty deque.

Projects

Design and implement class Polynomial
Design and implement class Tensor
Design and implement class SparseMatrix
Design and implement class Expression
(Big project) Design and implement a tiny relational database project.

Data Abstraction

9.1 Array

Array

Example of The sieve of Eratosthenes

9.2 Linked Lists

Linked Lists

Example of Josephus Election

Singly Linked Lists

Data Structure for List Node

Create a List Node

Delete a List Node

Deep Deletion

Organize a Linked List

Data Structure for Linked List

Insert at The Beginning

Traversing a Linked List

Another Data Structure for Linked List

Insert at The End

Remove from The Beginning

Search

Ordered Linked List

Ordered Linked List

Insert

Dummy Head Node

Sort

9.3 Variations on Linked List

Circular Linked Lists

Circular Linked Lists

Doubly Linked Lists

Doubly Linked Lists

Generalized Lists

How to Extend Linked List

Multi-Linked List

Multi-Linked List

Generalized Lists

9.4 Stack

Stack

Stack API

Stack applications

Function calls

Remove recursion

Arithmetic expression

Conversion of an infix expression to postfix

Example

Arithmetic expression evaluation

Implementation (simple)

9.5 Queue

Queue

Queue API

Queue applications

9.6 Deque

Deque

Deque API

9.7 Symbol Tables

Introduction

Symbol table applications

Abstract Data Type

Symbol-Table Abstract Data Type

Conventions

Ordered Symbol-Table Abstract Data Type

Examples of ordered symbol table API

Elementary Implementations

Array-based Symbol Table

Sequential Search

Binary Search

Interpolation Search

Selection

Cost summary for basic symbol-table implementations

9.8 Workshop

Quiz

Projects

9.9 References
